Ubiquiti EdgePoint S16, 16 Port PoE Outdoor WISP Switch - 4x 54v/24v PoE Ports, 12x 802.3af 48v PoE Ports - ESD Power Protection,Pole/Wall Mount

Ubiquiti EdgePoint S16

SKU:EP-S16

Description:
Application-specific WISP control point with (16) Gigabit RJ45 ports and (2) SFP ports

Features:

• Layer-2 switch with some layer-3 capabilities
• (16) GbE RJ45 ports
• (2) 1/10G SFP+ ports
• Weatherproof enclosure for outdoor use
• Mount : Pole/wall mount
• Wind loading: 153 N at 200 km/h (34 lbf at 125 mph)
• Wind survivability: 200 km/h (125 mph)
• Power method

- (1) DC terminal block
- 54V DC, 6A input
*Self-correcting polarity protection on DC terminal block only, diode red protection on all power inputs.

• Power supply: Min. 54V / 0.8A (Excludes PoE output)
• Supported voltage range: 42–56V DC (-48V is NOT supported)
• Max. power consumption: 40W (Excludes PoE output)
• Ambient operating temperature: -40 to 65° C (-40 to 149° F)
• Ambient operating humidity:10 to 90% noncondensing

Category: Network - UISP / UISP Wired
