Ubiquiti UniFi Indoor Cable Cat6A CMP, Category 6A Ethernet Cable, High-Speed Deployments In Environments, Require Plenum-Rated Cabling

Ubiquiti UniFi Indoor Cable Cat6A CMP

SKU: UACC-Cable-C6A-CMP

Description:
Category 6A Ethernet cable for high-speed deployments in environments that require plenum-rated cabling.

Features:

• Category 6A UTP communications multipurpose cable
• Plenum (CMP)-rated, fire-resistant jacket
• Anti-crosstalk divider
• Cable length 305 m

Category: Network - UniFi / Cables & Modules

Overview

• Length: 305 m (1,000 ft)
• Type: Category 6A
• Flame Rating: CMP
• Operating Environment: Indoor
• Box Dimensions: 494 x 302 x 481 mm
  (19.4 x 11.9 x 18.9")
• Box Weight: 21.3 kg (47 lb)
• Cable
• Jacket Color: White
• Jacket Diameter: 6.7 ±0.2 mm
• Jacket Material: Flame retardant polyvinyl chloride (FRPVC)
• Shielding Type: UTP
• Conductor Type: Solid bare copper
• Conductor Wire Gage: 23 AWG
• Bend Radius: Min. 26.8 mm (1.05 '')
• Twisting: 4 Twisted pairs with color code.
  Pair 1: white-blue / blue
  Pair 2: white-orange / orange
  Pair 3: white-green / green
  Pair 4: white-brown / brown
• Anti-Crosstalk Divider: Yes
• Ripcord: Yes
• Standards
• Electrical Transmission: ANSI/TIA -568.2-D
  ISO/IEC 11801-1 (Edition 2.2)
  IEC 61156-5 (Edition 2.1)
• Flame Test: NFPA 262 (CMP)
• Material and Construction: UL 444
  CSA 22.2 NO.214
  EU Directive 2011/65/EU (RoHS2)
  EU Directive 2006/95/EC (LVD)
• Installation Temperature: 0 to 60°C (32 to 140°F)
• Ambient Storage Temperature: -20 to 75°C (-4 to 167°F)
• Ambient Operating Temperature: -20 to 75°C (-4 to 167°F)
