Ubiquiti Dream Router 5G Max, Desktop Cloud Gateway, Full-Performance 5G, 3.4 Gbps, WiFi 7, 10G SFP+4-Port 2.5 GbE switch (1) PoE Port,SD Card Storage

Ubiquiti Dream Router 5G Max

SKU: UDR-5G-Max

Description:
Desktop Cloud Gateway with full-performance 5G up to 3.4 Gbps, WiFi 7, 10G SFP+, 4-port 2.5 GbE switch with (1) PoE port, and SD card storage.

Category: Network - UniFi / Console / Gateway

Overview

• Dimensions: 110 x 110 x 250 mm
  (4.3 x 4.3 x 9.8")
• UniFi Application Suite
• Network: Yes
• Protect: Yes
• Access: Yes
• Talk: Yes
• Connect: Yes
• Managed UniFi Devices: 30+
• Managed Cameras: (5) HD
  (2) 2K
  (1) 4K
• Simultaneous Users Connected: 300+
• Max. WAN Port Count: 4
• Default WAN Ports: (1) 10G SFP+
  (1) 2.5 GbE RJ45
• Port Layout
• 2.5 GbE RJ45: 4 (1 PoE)
  (2.5G/1G/100M)
• 10G SFP+: 1
  (10G/1G)
• IDS/IPS Throughput: 2.3 Gbps
• Form Factor: Desktop
• Coverage Area: 160 m² (1,750 ft²)

Security

• Stateful Firewall: Yes
• Application-Aware Layer 7 Firewall: Yes
• DPI & Traffic Identification: Yes
• Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps): Yes
• Content Filtering: Yes
• Intrusion Prevention (IPS/IDS): Yes
• Ad Blocking: Yes
• IDS/IPS Signatures: 20,000+ with CyberSecure

VPN & SD-WAN

• License-Free SD-WAN: Yes
• Site-to-Site VPN
• Site Magic: Yes
• IPsec: Yes
• OpenVPN: Yes
• VPN Server
• Identity Endpoint One-Click VPN: Yes
• Teleport Zero-Configuration VPN: Yes
• WireGuard: Yes
• OpenVPN: Yes
• L2TP: Yes
• VPN Client
• OpenVPN: Yes
• WireGuard: Yes
• Site-to-Site VPN Single Tunnel Throughput
• Site Magic: 20
• VPN Client Single Tunnel Throughput
• WireGuard: 8
• OpenVPN: 8

Networking

• Multi-WAN Load Balancing: Yes
• Dynamic Routing
• OSPF: Yes
• Advanced QoS: Yes
• Multicast DNS (mDNS): Yes
• Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT): Yes
• Integrated RADIUS Server: Yes
• RADIUS over TLS (RadSec): Yes
• Additional Internet Failover with UniFi LTE Backup: Yes
• Internet Quality and Outage Reporting: Yes
• MAC Address Table Size: 2,000
• Virtual Network Override: Yes

Integrated WiFi

• WiFi Standard: 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
• Throughput
• 6 GHz: 5.7 Gbps
• 5 GHz: 4.3 Gbps
• 2.4 GHz: 688 Mbps
• MIMO
• 6 GHz: 2 x 2 (DL/UL MU-MIMO)
• 5 GHz: 2 x 2 (DL/UL MU-MIMO)
• 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
• Antenna Gain
• 6 GHz: 8 dBi
• 5 GHz: 5 dBi
• 2.4 GHz: 4 dBi
• Max. TX Power
• 6 GHz: 22 dBm
• 5 GHz: 26 dBm
• 2.4 GHz: 23 dBm
• Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
• Max. BSSIDs: 4 per Radio
• Supported Data Rates
• 802.11be (WiFi 7): 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
• 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
• 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
• 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15 , HT 20/40)
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Cellular

• 5G NR
• Category: 5G NR Sub-6
• Frequency Bands: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79
• Max. TX Power: HPUE power class 2: 26 dBm
• 4G LTE
• Frequency Bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B18, B19, B20, B21, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71
• Max. TX Power: HPUE power class 2: 25 dBm
• 3G UMTS
• Frequency Bands: B1, B2, B4, B5, B8, B19
• Peak Data Speed
• 5G NSA: Downlink 3.4 Gbps
  Uplink 560 Mbps (Speed depends on network coverage and performance at the device location)
• 5G SA: Downlink 1.8 Gbps
  Uplink 650 Mbps
• 4G LTE: Downlink 1.6 Gbps
  Uplink 210 Mbps
• Antenna Gain: 617-960 MHz: 3 dBi
  1710-2700 MHz: 7 dBi
  3300-5000 MHz: 8 dBi
  5150~5925 MHz: 8 dBi
• SIM: (2) Nano SIM
  (1) Nano-SIM or eSIM (Nano-SIM 2 cannot be used when an eSIM is active)

Hardware

• NVR Storage: Pre-installed 64 GB microSD for NVR
• Expansion Slot: MicroSD Card (64 GB pre-installed microSD)
• PoE Budget: 15.4W
• Max. PoE Wattage per Port by PSE
• PoE: 15.4W
• Voltage Range PoE Mode: 44–57V
• Max. Power Consumption: 34.5W (Excluding PoE output)
• Power Method: DC jack (54V DC/1.1A)
• Power Supply: 54V DC/1.1A
  (Adapter included)
• Supported Voltage Range: 100–240V AC
• Heat Dissipation: 115 BTU/hr (Excluding PoE output)
• Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
• System Memory: 3 GB
• Weight: 1.4 kg (3.1 lb)
• Enclosure Material: Polycarbonate
• LCM Display: 4.7" touchscreen
• Management: Ethernet
  Bluetooth
• LEDs
• Ethernet: Yes
• SFP+: Yes
• System: Yes
• Button: (1) Factory reset
• ESD/EMP Protection: Air: ± 8kV, contact: ± 4kV
• Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
• Ambient Operating Humidity: 5 to 95% noncondensing
• NDAA Compliant: Yes
• Certifications: FCC, IC, CE, GCF, PTCRB, AT&T, T-Mobile, Wi-Fi Alliance®

Software

• Application Requirements
• Mobile App: UniFi iOS™: Version 10.33.0 and later
  UniFi Android™: Version 10.36.1 and later
